Boat Overview

  • Type
    Sail
  • Maker
    Albin Marine
  • Hull type
    Monohull
  • Hull Material
    Composite_material
  • Category
    Other Boats
  • Boat length (LOA)
    7.96 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerAlbin Marine
Maker websitehttps://en.wikipedia.org/wiki/Albin_Marine
ModelAlbin 82 MS
First built hull1975
Boat typeSail
Category Other Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed10.78 kmh
Length overall7.96 m
Length at waterline7.62 m
Beam overall2.87 m
Draft maximum0.95 m
Displacement3400.13 kg
Ballast weight899.93 kg
Helm1 wheel
Rudder1 rudder on skeg
CockpitCentral cockpit
Designer
NameValue
Naval architect
Name/StudioPer Brohäll
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area42.18 sq.m
Downwind sail area74.04 sq.m
Mainsail A183.00
Spinnaker A614.00
Spinnaker A140.00
Engine
NameValue
Engine A
Power35 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 7.65
Upwind SA to Displacement18.97
Downwind SA to Displacement33.3
Hull Displacement Speed 6.7
Displacement to Length (D/L) 214.17
Ballast to Displacement (B/D) 26.47
Capsize Screening Formula (CSF) 1.92
