Boat Overview

Boat Description

The Ballad 30 is a recreational keelboat, built predominantly of fibreglass, with wood trim. The hull is made from single skin polyester fibreglass, while the deck is a fibreglass-Divinicell sandwich.

The design was initially built by Albin Marine in Sweden from 1971 to 1982, with about 1,500 boats completed. After that company went out of business in 1982, the Ballard One-Design Association acquired the moulds and leased them to a number of companies, including Shipman Sweden AB and a few more boats were completed until 1998, but it is now out of production.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerAlbin Marine
Maker websitehttps://en.wikipedia.org/wiki/Albin_Marine
ModelBallad
First built hull1971
Last built hull1982
Price13,503 $
Boat typeSail
CategoryCruiser/Racer BoatsDaysailer BoatsMotorsailer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed10.27 kmh
Length overall9.12 m
Length at waterline6.88 m
Beam overall2.95 m
Draft maximum1.55 m
Displacement3,300.34 kg
Ballast weight1,549.92 kg
Helm1 tiller
Rudder1 rudder on skeg
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioRolf Magnusson
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area48.12 sq.m
Downwind sail area85.94 sq.m
Mainsail A171
Headsail A199
Spinnaker A753
Spinnaker A347
Spinnaker A271
Engine
NameValue
Engine A
FuelDiesel
MakerVolvo Penta
ModelMD6A
Power10 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement22.08
Downwind SA to Displacement39.43
Hull Displacement Speed 0.05
Displacement to Length (D/L) 6.37
Ballast to Displacement (B/D) 0.47
Capsize Screening Formula (CSF) 2
