Boat Overview

Boat Description

The Cumulus, also called the Albin Cumulus, is a Swedish sailboat that was designed by Peter Norlin as a cruiser-racer and first built in 1978. The design was built by Albin Marine in Sweden from 1978 to 1985, with 567 examples completed. The company also built boats in Taiwan. In 2008 the brand was sold to Bladen Composites in the United States.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerAlbin Marine
Maker websitehttps://en.wikipedia.org/wiki/Albin_Marine
ModelCumulus
First built hull1978
Last built hull1985
Price15,742 $
Boat typeSail
CategoryCruiser/Racer BoatsDaysailer BoatsMotorsailer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed10.19 kmh
Length overall8.56 m
Length at waterline6.8 m
Beam overall2.87 m
Draft maximum1.6 m
Displacement3,200.09 kg
Ballast weight1,275.5 kg
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioPeter Norlin
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Upwind sail area35.49 sq.m
Mainsail A188
Headsail A189.89
Spinnaker A194
Engine
NameValue
Engine A
FuelDiesel
MakerYanmar
Power12 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Upwind SA to Displacement16.62
Displacement to Length (D/L) 6.33
Ballast to Displacement (B/D) 0.4
Capsize Screening Formula (CSF) 1.96
