Boat Overview

  • Type
    Sail
  • Maker
    Albin Marine
  • Hull type
    Monohull
  • Hull Material
    Fiberglass
  • Category
    Cruiser Boats
  • Boat length (LOA)
    9.91 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerAlbin Marine
Maker websitehttps://en.wikipedia.org/wiki/Albin_Marine
ModelAlbin Nova 33
First built hull1981
Boat typeSail
Category Cruiser Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed11.06 kmh
Length overall9.91 m
Length at waterline7.99 m
Beam overall3.17 m
Draft maximum1.71 m
Displacement3699.95 kg
Ballast weight1749.96 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioPeter Norlin
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angleSwept-back
Upwind sail area47.01 sq.m
Engine
NameValue
Engine A
Power15 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Upwind SA to Displacement19.99
Hull Displacement Speed 6.86
Displacement to Length (D/L) 202.48
Ballast to Displacement (B/D) 47.3
Capsize Screening Formula (CSF) 2.07
