Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
19.63 m
Specs
Main
| Maker | Amel |
| Maker website | https://www.amel.fr |
| Model | 64 |
| First built hull | 2010 |
| Price | 2,150,000 € |
| Boat type | Sail |
| Category | Cruiser BoatsCenter Cockpit Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 16.21 kmh |
| Mast height | 23.5 m |
| Length overall | 19.63 m |
| Length at waterline | 17.25 m |
| Beam overall | 5.64 m |
| Draft maximum | 2.17 m |
| Displacement | 38,800 kg |
| Ballast weight | 8,500 kg |
| Helm | 1 wheel |
| Rudder | 1 rudder on skeg |
| Cockpit | Central cockpit |
Designer
| Naval architect | |
| Name/Studio | Berret-Racoupeau Yacht Design |
| Website | http://www.berret-racoupeau.com/ |
Rig & Sails
| Mast | 77.1 |
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 175.96 sq.m |
| Downwind sail area | 285.96 sq.m |
Engine
| Engine A | |
| Power | 180 HP |
| Type | Inboard |
Storage
| Fuel tank A | 1,399.85 liter |
| Water tank A | 900.17 liter |
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.03 |
| Upwind SA to Displacement | 15.62 |
| Downwind SA to Displacement | 25.38 |
| Hull Displacement Speed | 0.03 |
| Displacement to Length (D/L) | 10.08 |
| Ballast to Displacement (B/D) | 0.22 |
| Capsize Screening Formula (CSF) | 1.68 |
