Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
9.78 m
Specs
Main
Name | Value |
---|---|
Maker | Amel |
Maker website | https://www.amel.fr |
Model | Fango |
First built hull | 1985 |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 11.15 kmh |
Mast height | 15.27 m |
Length overall | 9.78 m |
Length at waterline | 8.17 m |
Beam overall | 3.41 m |
Draft maximum | 1.58 m |
Displacement | 4,999.94 kg |
Ballast weight | 1,599.82 kg |
Ballast type | Cast iron |
Helm | 1 wheel |
Rudder | 1 rudder on skeg |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Henri Amel ; Jacques Carteau |
Rig & Sails
Name | Value |
---|---|
Mast | 50.11 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire |
Upwind sail area | 49.98 sq.m |
Downwind sail area | 55 sq.m |
Mainsail A | 183.00 |
Spinnaker A | 409.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 28 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.02 |
Upwind SA to Displacement | 17.39 |
Downwind SA to Displacement | 19.13 |
Hull Displacement Speed | 0.02 |
Displacement to Length (D/L) | 6.94 |
Ballast to Displacement (B/D) | 0.32 |
Capsize Screening Formula (CSF) | 2.02 |
