Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
10.73 m
Specs
Main
| Maker | Amel |
| Maker website | https://www.amel.fr |
| Model | Kirk |
| First built hull | 1971 |
| Boat type | Sail |
| Category | Cruiser BoatsCenter Cockpit Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 11.46 kmh |
| Mast height | 14.36 m |
| Length overall | 10.73 m |
| Length at waterline | 8.6 m |
| Beam overall | 2.78 m |
| Beam hull | 1.56 m |
| Draft maximum | 1.65 m |
| Displacement | 6,499.97 kg |
| Ballast weight | 1,930.03 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 semi-spade rudder |
| Cockpit | Central cockpit |
Designer
| Naval architect | |
| Name/Studio | Henri Amel |
| Website | http://www.amel.fr/ |
Rig & Sails
| Mast | 47.11 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 52.95 sq.m |
| Downwind sail area | 91.88 sq.m |
Engine
| Engine A | |
| Power | 25 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.03 |
| Upwind SA to Displacement | 15.46 |
| Downwind SA to Displacement | 26.83 |
| Hull Displacement Speed | 0.03 |
| Displacement to Length (D/L) | 7.12 |
| Ballast to Displacement (B/D) | 0.3 |
| Capsize Screening Formula (CSF) | 1.5 |
