Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
13.75 m
Specs
Main
| Maker | Amel |
| Maker website | https://www.amel.fr |
| Model | Santorin |
| First built hull | 1989 |
| Price | 264,000 € |
| Boat type | Sail |
| Category | Cruiser BoatsCenter Cockpit Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.78 kmh |
| Mast height | 16.79 m |
| Length overall | 13.75 m |
| Length at waterline | 10.7 m |
| Beam overall | 3.99 m |
| Draft maximum | 1.89 m |
| Displacement | 11,000.06 kg |
| Ballast weight | 3,699.95 kg |
| Helm | 1 wheel |
| Rudder | 1 rudder on skeg |
| Cockpit | Central cockpit |
Designer
| Naval architect | |
| Name/Studio | Jacques Carteau |
Rig & Sails
| Mast | 55.1 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 90.02 sq.m |
| Downwind sail area | 115.01 sq.m |
Engine
| Engine A | |
| Power | 50 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.03 |
| Upwind SA to Displacement | 18.51 |
| Downwind SA to Displacement | 23.65 |
| Hull Displacement Speed | 0.03 |
| Displacement to Length (D/L) | 7.94 |
| Ballast to Displacement (B/D) | 0.34 |
| Capsize Screening Formula (CSF) | 1.81 |
