Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
12.5 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Amel |
| Maker website | https://www.amel.fr |
| Model | Sharki |
| First built hull | 1979 |
| Boat type | Sail |
| Category | Cruiser BoatsCenter Cockpit Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Name | Value |
|---|---|
| Top speed | 12.17 kmh |
| Length overall | 12.5 m |
| Length at waterline | 9.48 m |
| Beam overall | 3.38 m |
| Draft maximum | 1.86 m |
| Displacement | 9,700.06 kg |
| Ballast weight | 3,200.09 kg |
| Helm | 1 wheel |
| Rudder | 1 rudder on skeg |
| Cockpit | Central cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Henri Amel ; Jacques Carteau |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 75.99 sq.m |
| Downwind sail area | 93 sq.m |
| Mainsail A | 237.00 |
| Spinnaker A | 474.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 50 HP |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.03 |
| Upwind SA to Displacement | 16.99 |
| Downwind SA to Displacement | 20.8 |
| Hull Displacement Speed | 0.03 |
| Displacement to Length (D/L) | 7.47 |
| Ballast to Displacement (B/D) | 0.33 |
| Capsize Screening Formula (CSF) | 1.6 |
