Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
13.11 m
Specs
Main
| Maker | Archambault |
| Maker website | https://en.wikipedia.org/wiki/Archambault_Boats |
| Model | A13 |
| First built hull | 2014 |
| Price | 326,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Length overall | 13.11 m |
| Beam overall | 4.18 m |
| Draft maximum | 2.62 m |
| Displacement | 6,450.08 kg |
| Helm | 1 tiller (helm wheel in option) |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Michel Joubert |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 101.54 sq.m |
| Downwind sail area | 237 sq.m |
Engine
| Engine A | |
| Power | 30 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.08 |
| Upwind SA to Displacement | 29.81 |
| Downwind SA to Displacement | 69.56 |
| Hull Displacement Speed | 0.08 |
| Capsize Screening Formula (CSF) | 2.26 |
