2012 Archambault A27 - Fin Keel

No gallery images

2012 Archambault A27 - Fin Keel
Preview

Boat Overview

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerArchambault
Maker websitehttps://en.wikipedia.org/wiki/Archambault_Boats
ModelA27 - Fin Keel
First built hull2012
VersionFin Keel
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed10.78 kmh
Length overall8.38 m
Length at waterline7.62 m
Beam overall2.77 m
Headroom1.58 m
Draft maximum1.77 m
Displacement2,150.03 kg
Ballast weight827.81 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioMichel Joubert ; Bernard Nivelt
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area41.53 sq.m
Downwind sail area96.99 sq.m
Mainsail A258.00
Spinnaker A786.00
Engine
NameValue
Engine A
Power13 HP
TypeOutboard or inboard engine
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 14.63
Upwind SA to Displacement25.35
Downwind SA to Displacement59.21
Hull Displacement Speed 6.7
Displacement to Length (D/L) 135.43
Ballast to Displacement (B/D) 38.5
Capsize Screening Formula (CSF) 2.17
