Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
8.38 m
Specs
Main
| Maker | Archambault |
| Maker website | https://en.wikipedia.org/wiki/Archambault_Boats |
| Model | A27 - Swing Keel |
| First built hull | 2012 |
| Version | Swing Keel |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 10.78 kmh |
| Length overall | 8.38 m |
| Length at waterline | 7.62 m |
| Beam overall | 2.77 m |
| Beam hull | 1.58 m |
| Draft maximum | 1.86 m |
| Displacement | 2,150.03 kg |
| Ballast weight | 827.81 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 41.53 sq.m |
| Downwind sail area | 96.99 sq.m |
Engine
| Engine A | |
| Power | 13 HP |
| Type | outboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 25.35 |
| Downwind SA to Displacement | 59.21 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 6.7 |
| Ballast to Displacement (B/D) | 0.39 |
| Capsize Screening Formula (CSF) | 2.17 |
