Boat Overview

  • Type
    Sail
  • Maker
    Archambault
  • Hull type
    Monohull
  • Hull Material
    Fiberglass
  • Category
    Racer Boats
  • Boat length (LOA)
    10.61 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerArchambault
ModelA35
First built hull2006
Boat typeSail
Category Racer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed11.86 kmh
Mast height19.51 m
Length overall10.61 m
Length at waterline9.20 m
Beam overall3.57 m
Headroom1.86 m
Draft maximum1.86 m
Displacement4599.88 kg
Ballast weight1900.10 kg
Ballast typeLead
Helm1 tiller (helm wheel in option)
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioMichel Joubert ; Bernard Nivelt
Rig & Sails
NameValue
Mast64
SparsMast and boom in Aluminum (carbon fiber as an option)
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area67.54 sq.m
Downwind sail area133.04 sq.m
Mainsail A409.00
Spinnaker A883.00
Spinnaker A1023.00
Engine
NameValue
Engine A
Power21 HP
TypeInboard, Diesel
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 13.97
Upwind SA to Displacement24.84
Downwind SA to Displacement48.92
Hull Displacement Speed 7.36
Displacement to Length (D/L) 164.37
Ballast to Displacement (B/D) 41.31
Capsize Screening Formula (CSF) 2.16
