Boat Overview

  • Type
    Sail
  • Maker
    Archambault ; BG Race
  • Hull type
    Monohull
  • Hull Material
    Composite_material
  • Category
    Racer Boats
  • Boat length (LOA)
    12.01 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerArchambault ; BG Race
Maker websitehttps://en.wikipedia.org/wiki/Archambault_Boats
ModelA40 RC
First built hull2003
Price205 €
Boat typeSail
Category Racer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed12.68 kmh
Length overall12.01 m
Length at waterline10.58 m
Beam overall3.78 m
Headroom2.04 m
Draft maximum2.47 m
Displacement6499.97 kg
Ballast weight3499.92 kg
Ballast typeLead
Helm2 wheels
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioMichel Joubert ; Bernard Nivelt
Rig & Sails
NameValue
SparsMast and boom in Aluminum (carbon fiber as an option)
Standing riggingDyform
Number of spreaders2
Spreaders angle20 °
Upwind sail area91.05 sq.m
Downwind sail area184.97 sq.m
Mainsail A549.00
Spinnaker A1442.00
Engine
NameValue
Engine A
Power29 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 14.89
Upwind SA to Displacement26.59
Downwind SA to Displacement54.02
Hull Displacement Speed 7.89
Displacement to Length (D/L) 153.11
Ballast to Displacement (B/D) 53.85
Capsize Screening Formula (CSF) 2.04
