Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.57 m
Specs
Main
| Maker | Archambault |
| Maker website | https://en.wikipedia.org/wiki/Archambault_Boats |
| Model | Grand Surprise |
| First built hull | 1999 |
| Price | 67,500 € |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.67 kmh |
| Length overall | 9.57 m |
| Length at waterline | 8.96 m |
| Beam overall | 2.77 m |
| Beam hull | 1.68 m |
| Draft maximum | 2.07 m |
| Displacement | 2,649.88 kg |
| Ballast weight | 1,050.07 kg |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 56.02 sq.m |
| Downwind sail area | 171.22 sq.m |
Engine
| Engine A | |
| Power | 19 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.11 |
| Upwind SA to Displacement | 29.75 |
| Downwind SA to Displacement | 90.94 |
| Hull Displacement Speed | 0.11 |
| Displacement to Length (D/L) | 7.27 |
| Ballast to Displacement (B/D) | 0.4 |
| Capsize Screening Formula (CSF) | 2.02 |
