Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.65 m
Specs
Main
Name | Value |
---|---|
Maker | Archambault |
Maker website | https://en.wikipedia.org/wiki/Archambault_Boats |
Model | Surprise Fin keel |
First built hull | 1977 |
Version | Fin keel |
Price | 32,700 € |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 10.04 kmh |
Mast height | 9.81 m |
Length overall | 7.65 m |
Length at waterline | 6.64 m |
Beam overall | 2.47 m |
Headroom | 1.25 m |
Draft maximum | 1.58 m |
Displacement | 1,349.89 kg |
Ballast weight | 600.1 kg |
Ballast type | Cast iron |
Helm | 1 tiller |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
Name | Value |
---|---|
Mast | 32.2 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 30.47 sq.m |
Downwind sail area | 61.5 sq.m |
Mainsail A | 178.00 |
Spinnaker A | 484.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 10 HP |
Type | Outboard Engine |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.06 |
Upwind SA to Displacement | 25.37 |
Downwind SA to Displacement | 51.21 |
Hull Displacement Speed | 0.06 |
Displacement to Length (D/L) | 6.26 |
Ballast to Displacement (B/D) | 0.44 |
Capsize Screening Formula (CSF) | 2.25 |
