Boat Overview

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerArchambault
Maker websitehttps://en.wikipedia.org/wiki/Archambault_Boats
ModelSurprise Swing keel
First built hull1977
VersionSwing keel
Price32,700 €
Boat typeSail
CategoryRacer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed10.04 kmh
Mast height9.81 m
Length overall7.65 m
Length at waterline6.64 m
Beam overall2.47 m
Headroom1.25 m
Draft maximum1.58 m
Displacement1,349.89 kg
Ballast weight600.1 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Trailerable
Designer
NameValue
Naval architect
Name/StudioMichel Joubert ; Bernard Nivelt
Rig & Sails
NameValue
Mast32.2
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angleSwept-back
Upwind sail area30.47 sq.m
Downwind sail area61.5 sq.m
Mainsail A178.00
Spinnaker A484.00
Engine
NameValue
Engine A
Power10 HP
TypeOutboard Engine
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 13.77
Upwind SA to Displacement25.37
Downwind SA to Displacement51.21
Hull Displacement Speed 6.26
Displacement to Length (D/L) 128.24
Ballast to Displacement (B/D) 44.46
Capsize Screening Formula (CSF) 2.25
