Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
10.09 m
Specs
Main
| Maker | Archambault |
| Maker website | https://en.wikipedia.org/wiki/Archambault_Boats |
| Model | M34 |
| First built hull | 2010 |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 12.41 kmh |
| Length overall | 10.09 m |
| Length at waterline | 10.09 m |
| Beam overall | 2.77 m |
| Beam hull | 1.74 m |
| Draft maximum | 2.5 m |
| Displacement | 2,700 kg |
| Ballast weight | 1,050 kg |
| Ballast type | Carbon fiber fin with lead bulb |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
| Spars | Mast in Carbon fiber and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | 20 ° |
| Upwind sail area | 70.98 sq.m |
| Downwind sail area | 171.96 sq.m |
Engine
| Engine A | |
| Power | 20 HP |
| Type | Inboard |
Storage
| Fuel tank A | 49.97 liter |
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.11 |
| Upwind SA to Displacement | 37.23 |
| Downwind SA to Displacement | 90.2 |
| Hull Displacement Speed | 0.11 |
| Displacement to Length (D/L) | 7.71 |
| Ballast to Displacement (B/D) | 0.39 |
| Capsize Screening Formula (CSF) | 2.01 |
