Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.27 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Archambault |
| Maker website | https://en.wikipedia.org/wiki/Archambault_Boats |
| Model | Suspens Fin keel |
| First built hull | 1979 |
| Version | Fin keel |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Top speed | 10.91 kmh |
| Mast height | 13.53 m |
| Length overall | 9.27 m |
| Length at waterline | 7.83 m |
| Beam overall | 2.77 m |
| Draft maximum | 1.56 m |
| Displacement | 2,775.08 kg |
| Ballast weight | 830.07 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
| Name | Value |
|---|---|
| Mast | 44.4 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back |
| Upwind sail area | 52.86 sq.m |
| Downwind sail area | 106.84 sq.m |
| Mainsail A | 288.00 |
| Spinnaker A | 861.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 27.22 |
| Downwind SA to Displacement | 55.02 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 6.79 |
| Ballast to Displacement (B/D) | 0.3 |
| Capsize Screening Formula (CSF) | 1.99 |
