Boat Overview

Boat Description

When it was time to design the Arcona 430, there were a long list of ideas and thoughts from the Arcona Yachts team on how build a yacht without compromises and standard solutions; this list arose as a direct result from many years of experience in sailing, yacht design and boat building. The outcome was a yacht awarded European Yacht of the Year 2009 – Arcona 430.

She is a full sized 43 feet yacht with sailing capabilities above normal. She’s just as hot on the race courses as she is safe and easy to handle for the family during cruising. The Arcona 430 has the same technically advanced construction, built to a superb quality and with modern technology, like all Arcona yachts are. Arcona 430 is full of practical details and smart solutions – she is an extraordinary yacht.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerArcona Yachts
Maker websitehttps://www.arconayachts.se
Model430
First built hull2008
Price398,223 $
Boat typeSail
CategoryCruiser BoatsMotorsailer BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins3
Births6
Heads2
General
NameValue
Top speed13.57 kmh
Length overall13.14 m
Length at waterline12.07 m
Beam overall3.99 m
Draft maximum2.32 m
Displacement9,200.21 kg
Ballast weight3,600.16 kg
Ballast typeCast iron fin with lead bulb
Helm1 wheel
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioStefan Qviberg
Websitehttp://www.sqyachtdesign.se/
Rig & Sails
NameValue
SparsMast and boom in Aluminum (carbon fiber as an option)
Standing riggingDyform discontinuous
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area128.02 sq.m
Downwind sail area196.95 sq.m
Mainsail A667
Headsail A710
Headsail B558
Spinnaker A1453
Engine
NameValue
Engine A
FuelDiesel
MakerYanmar
Power40 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement29.66
Downwind SA to Displacement45.62
Hull Displacement Speed 0.05
Displacement to Length (D/L) 8.43
Ballast to Displacement (B/D) 0.39
Capsize Screening Formula (CSF) 1.92
