Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
4.94 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Astus Boats |
| Maker website | https://www.astusboats.com |
| Model | Astus 16.5 - Sport |
| First built hull | 2016 |
| Version | Sport |
| Price | 15,600 € |
| Boat type | Sail |
| Category | Trimaran Boats |
| Hull type | Trimaran |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Mast height | 7.96 m |
| Length overall | 4.94 m |
| Length at waterline | 4.91 m |
| Beam overall | 3.84 m |
| Draft maximum | 1.13 m |
| Displacement | 210.01 kg |
| Helm | 1 tiller |
| Rudder | 1 transom hung rudder (main hull) |
| Cockpit | Open aft cockpit |
| Trailerable |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | VPLP Design |
| Website | http://www.vplp.fr |
Rig & Sails
| Name | Value |
|---|---|
| Rotating spars | |
| Mast | 26.11 |
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back (diamond) |
| Upwind sail area | 17 sq.m |
| Downwind sail area | 31.49 sq.m |
| Mainsail A | 124.00 |
| Mainsail B | 59.00 |
| Mainsail C | 215.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Type | Outboard engine ; Gas |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.11 |
| Upwind SA to Displacement | 48.93 |
| Downwind SA to Displacement | 90.64 |
| Hull Displacement Speed | 0.11 |
| Displacement to Length (D/L) | 5.38 |
| Capsize Screening Formula (CSF) | 6.52 |
