Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
6.13 m
Specs
Main
Name | Value |
---|---|
Maker | Astus Boats |
Maker website | https://www.astusboats.com |
Model | Astus 20.1 |
First built hull | 2004 |
Boat type | Sail |
Category | Trimaran Boats |
Hull type | Trimaran |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Length overall | 6.13 m |
Length at waterline | 5.85 m |
Beam overall | 3.9 m |
Draft maximum | 1.13 m |
Displacement | 375.12 kg |
Helm | 1 tiller |
Rudder | 1 transom hung rudder (main hull) |
Cockpit | Open aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Stéphan Vallet |
Website | http://vdesign.fr/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back (diamond) |
Upwind sail area | 22.48 sq.m |
Downwind sail area | 40.04 sq.m |
Mainsail A | 172.00 |
Spinnaker A | 258.00 |
Spinnaker A | 215.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard Engine ; Gas |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.09 |
Upwind SA to Displacement | 43.95 |
Downwind SA to Displacement | 78.28 |
Hull Displacement Speed | 0.09 |
Displacement to Length (D/L) | 5.87 |
Capsize Screening Formula (CSF) | 5.46 |
