Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.96 m
Specs
Main
Name | Value |
---|---|
Maker | Astus Boats |
Maker website | https://www.astusboats.com |
Model | Astus 22 |
First built hull | 2008 |
Price | 36,300 € |
Boat type | Sail |
Category | Trimaran Boats |
Hull type | Trimaran |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Mast height | 9.63 m |
Length overall | 7.96 m |
Length at waterline | 6.64 m |
Beam overall | 4.6 m |
Headroom | 1.74 m |
Draft maximum | 1.34 m |
Displacement | 1,379.83 kg |
Helm | 1 tiller |
Rudder | 1 transom hung rudder (main hull) |
Cockpit | Open aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Stéphan Vallet |
Website | http://vdesign.fr/ |
Rig & Sails
Name | Value |
---|---|
Mast | 31.6 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back (diamond) |
Upwind sail area | 27.96 sq.m |
Mainsail A | 205.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard engine ; Gas |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 22.95 |
Displacement to Length (D/L) | 6.26 |
Capsize Screening Formula (CSF) | 4.17 |
