Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.44 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Astus Boats |
| Maker website | https://www.astusboats.com |
| Model | Astus 24 |
| First built hull | 2014 |
| Price | 53,000 € |
| Boat type | Sail |
| Category | Trimaran Boats |
| Hull type | Trimaran |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Mast height | 10.49 m |
| Length overall | 7.44 m |
| Beam overall | 5.24 m |
| Headroom | 1.74 m |
| Draft maximum | 1.25 m |
| Displacement | 850.03 kg |
| Helm | 1 tiller |
| Rudder | 1 transom hung rudder (main hull) |
| Cockpit | Open aft cockpit |
| Trailerable |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Eric Henseval |
| Website | http://hensevalyachtdesign.jimdo.com/ |
Rig & Sails
| Name | Value |
|---|---|
| Mast | 34.4 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back (diamond) |
| Upwind sail area | 34.56 sq.m |
| Downwind sail area | 51 sq.m |
| Mainsail A | 237.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Type | Outboard engine ; Gas |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 39.17 |
| Downwind SA to Displacement | 57.8 |
| Hull Displacement Speed | 0.07 |
| Capsize Screening Formula (CSF) | 5.59 |
