2005 Beneteau 34.7

3112

Report error

2005 Beneteau 34.7

No galley images

2005 Beneteau 34.7
Preview

Boat Overview

  • Type
    Sail
  • Maker
    Beneteau
  • Hull type
    Monohull
  • Hull Material
    Fiberglass
  • Category
    Cruiser/Racer Boats
  • Boat length (LOA)
    10.36 m

Boat Description

The Beneteau 34.7 is a recreational keelboat, built predominantly of glassfibre, with wood trim. The hull is solid fibreglass below the waterline; above the waterline the hull and the deck are balsa-cored. It has a fractional sloop rig, with a keel-stepped mast, two sets of swept spreaders and composite, or optional carbon fibre, spars with steel rod standing rigging. It has a retractable carbon fibre bowsprit. The hull has a slightly raked stem, an open reverse transom, an internally mounted spade-type rudder controlled by a large 63 in (160 cm) diameter wheel and a fixed iron fin keel with a weighted "torpedo" bulb, or optional shoal-draft keel.

The design has sleeping accommodation for three people in two cabins. It has a double berth in the starboard aft cabin and a single in the port aft cabin. There are two straight settees in the main salon around a drop-leaf table. The galley is located on the port side, just forward of the companionway ladder. The galley is "L"-shaped and is equipped with a two-burner stove, an icebox and a sink. A navigation station is opposite the galley, on the starboard side. The head is located in the forepeak.

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerBeneteau
Maker websitehttps://www.beneteau.com/en
Model34.7
First built hull2005
Last built hull2009
VersionDeep draft
Price119000 $
Boat typeSail
Category Cruiser/Racer Boats
Hull typeMonohull
Hull materialMonohull
Cabins1
Births5
Heads1
General
NameValue
Top speed11.54 kmh
Mast height15.58 m
Length overall10.36 m
Length at waterline8.75 m
Beam overall3.38 m
Headroom1.56 m
Draft maximum2.04 m
Displacement4520.04 kg
Ballast weight1670.13 kg
Ballast typeLead
Helm1 wheel
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioFarr Yacht Design
Websitehttp://www.farrdesign.com
Rig & Sails
NameValue
Mast51.1
SparsMast and boom in Aluminum
Standing riggingDyform
Number of spreaders2
Spreaders angle20 °
Upwind sail area70.33 sq.m
Mainsail A380
Headsail A377
Engine
NameValue
Engine A
FuelDiesel
Power21 HP
TypeInboard
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 13.13
Upwind SA to Displacement26.16
Hull Displacement Speed 7.18
Displacement to Length (D/L) 188.18
Ballast to Displacement (B/D) 36.95
Capsize Screening Formula (CSF) 2.06
