1980 Beneteau Evasion 34

1222

Report error

1980 Beneteau Evasion 34

No gallery images

1980 Beneteau Evasion 34
Preview

Boat Overview

Boat Description

André BENETEAU likes high-performing sailboats and he is very attached to the notion of comfort. In designing the Evasion 34, he combined these 2 qualities in a particularly elegant “fifty”.  The Evasion 34 has a powerful full with soft movements. Very stiff, it is an excellent sailer whose split sails (cutter rigging) facilitates handling and reduces sail changes.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerBeneteau
Maker websitehttps://www.beneteau.com
ModelEvasion 34
First built hull1980
Last built hull1984
VersionFin keel
Price30,000 €
Boat typeSail
CategoryCruiser BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins3
Births6
Heads1
General
NameValue
Top speed11.59 kmh
Length overall10.7 m
Length at waterline8.57 m
Beam overall3.51 m
Headroom1.56 m
Draft maximum1.55 m
Displacement5,499.8 kg
Ballast weight2,199.92 kg
Ballast typeCast iron
Helm2 wheels
Rudder1 rudder on skeg
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioBeneteau
Websitehttp://www.beneteau.com
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area61.69 sq.m
Downwind sail area112.04 sq.m
Mainsail A237
Headsail A427
Headsail B241
Headsail C65
Spinnaker A969
Engine
NameValue
Engine A
FuelDiesel
Power50 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.04
Upwind SA to Displacement20.14
Downwind SA to Displacement36.57
Hull Displacement Speed 0.04
Displacement to Length (D/L) 7.1
Ballast to Displacement (B/D) 0.4
Capsize Screening Formula (CSF) 2
