Boat Overview

Boat Description

The Figaro BENETEAU 3 is the first production foiling one-design monohull ever to be designed. A distillation of technology and innovation, it results from a collaboration between group BENETEAU’s best experts and the Van Peteghem Lauriot-Prévost (VPLP) office, the architects of the two last boats to win the Vendée Globe.

The prototype has been tested and the production of the boat has been launched.  It will enter the ISO/World Sailing design category A.

The specifications define the FB3 monohull as being as reliable as its predecessor, the FB2.  It is equipped with foils, a better performing ballast-free hull, a more slender and deeper keel, a setback mast and a more extensive and larger sail plan.

Contrary to Imoca 60 foils, the FB3 foils will have an inward-facing profile. The way they operate is different. They are versatile foils that create drift reduction and improve the boat’s righting moment, without increasing the movement, which improves the boat’s performance. Deep, with a straight blade, it creates minimum drag. Supplementary drift reduction is provided by the foils.Made of foam sandwich, fibreglass and polyester infused resin, it corresponds to current designs and is ballast-free.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerBeneteau
Maker websitehttps://www.beneteau.com
ModelFigaro 3
First built hull2019
Price160.96 $
Boat typeSail
CategoryRacer BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Length overall10.97 m
Length at waterline9.45 m
Beam overall3.51 m
Draft maximum2.49 m
Draft minimum2.49 m
Displacement3,175.14 kg
CE classification A3
CE classification B4
CE classification C6
Designer
NameValue
Naval architect
Name/StudioVPLP Design
Websitehttp://www.vplp.fr
Rig & Sails
NameValue
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area68.28 sq.m
Downwind sail area144.46 sq.m
Mainsail A425
Headsail A328
Spinnaker A1130
Engine
NameValue
Engine A
FuelDiesel
Power24 HP
TypeInboard
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.08
Hull Displacement Speed 0.08
Displacement to Length (D/L) 7.46
Capsize Screening Formula (CSF) 2.41
