Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.78 m
Specs
Main
Name | Value |
---|---|
Maker | Beneteau |
Maker website | https://www.beneteau.com |
Model | Oceanis Clipper 323 |
First built hull | 2003 |
Last built hull | 2007 |
Price | 80,000 $ |
Boat type | Sail |
Category | Cruiser BoatsDaysailer BoatsCutter Boats |
Hull type | Monohull |
Hull material | Fiberglass |
Cabins | 2 |
Births | 4 |
Heads | 1 |
General
Name | Value |
---|---|
Top speed | 11.65 kmh |
Mast height | 14.84 m |
Length overall | 9.78 m |
Length at waterline | 8.9 m |
Beam overall | 3.29 m |
Headroom | 1.98 m |
Draft maximum | 1.56 m |
Displacement | 4,230.2 kg |
Ballast weight | 987.92 kg |
Ballast type | Cast iron |
Helm | 1 wheel |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Finot Conq Architectes |
Website | http://www.finot-conq.com |
Rig & Sails
Name | Value |
---|---|
Mast | 48.7 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | 25 ° |
Upwind sail area | 50.73 sq.m |
Downwind sail area | 101.82 sq.m |
Mainsail A | 305 |
Headsail A | 241 |
Spinnaker A | 791 |
Engine
Name | Value |
---|---|
Engine A | |
Fuel | Diesel |
Power | 21 HP |
Type | Inboard |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 19.72 |
Downwind SA to Displacement | 39.59 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 7.24 |
Ballast to Displacement (B/D) | 0.23 |
Capsize Screening Formula (CSF) | 2.05 |
Notes
This boat can be found in Deep Draft, Shoal Draft, Keel and Centerboard.
