Boat Overview

Boat Description

Beneteau R/C 30 is a 28’11” (8.8m) cruiser-racer sailboat designed by Bureau Mauric. This boat was built between 1977 and 1981 by Beneteau (France) with 969 hulls completed. The Fin keel version adopts a classical fin configuration, the easiest option to provide a low center of gravity.


Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerBeneteau
Maker websitehttps://www.beneteau.com
ModelR/C 30
First built hull1977
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialMonohull
Cabins1
Births4
Heads1
General
NameValue
Top speed10.88 kmh
Mast height11.92 m
Length overall8.99 m
Length at waterline7.77 m
Beam overall2.9 m
Headroom1.83 m
Draft maximum1.77 m
Displacement4,080.06 kg
Ballast weight1,700.06 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 semi-spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioBureau Mauric
Websitehttp://www.mauric.com
Rig & Sails
NameValue
Mast39.1
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area48.68 sq.m
Downwind sail area85.66 sq.m
Mainsail A168
Headsail A355
Headsail B274
Spinnaker A753
Engine
NameValue
Engine A
FuelDiesel
Power15 HP
TypeInboard
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 6.22
Upwind SA to Displacement19.39
Downwind SA to Displacement34.12
Hull Displacement Speed 6.77
Displacement to Length (D/L) 242.18
Ballast to Displacement (B/D) 41.67
Capsize Screening Formula (CSF) 1.83
