Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.53 m
Specs
Main
| Maker | Archambault by BG Race |
| Maker website | https://www.archambault-by-bgrace.com |
| Model | M 7.50 |
| First built hull | 2015 |
| Price | 30,200 € |
| Boat type | Sail |
| Category | Sports Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 10.22 kmh |
| Mast height | 10.61 m |
| Length overall | 7.53 m |
| Length at waterline | 6.89 m |
| Beam overall | 1.86 m |
| Draft maximum | 1.22 m |
| Displacement | 800.14 kg |
| Ballast weight | 474.91 kg |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
| Trailerable |
Designer
| Naval architect | |
| Name/Studio | Gilles Bréteché |
Rig & Sails
| Mast | 34.8 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 20 ° |
| Upwind sail area | 22.76 sq.m |
| Downwind sail area | 54.91 sq.m |
Engine
| Engine A | |
| Type | outboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.08 |
| Upwind SA to Displacement | 26.86 |
| Downwind SA to Displacement | 64.78 |
| Hull Displacement Speed | 0.08 |
| Displacement to Length (D/L) | 6.37 |
| Ballast to Displacement (B/D) | 0.59 |
| Capsize Screening Formula (CSF) | 2.02 |
