Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.19 m
Specs
Main
Name | Value |
---|---|
Maker | Archambault by BG Race |
Maker website | https://www.archambault-by-bgrace.com |
Model | Tizh 40 |
First built hull | 2014 |
Price | 415,000 € |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Length overall | 12.19 m |
Beam overall | 4.3 m |
Draft maximum | 2.77 m |
Displacement | 4,500.09 kg |
Ballast type | Lateral water ballasts |
Helm | 1 tiller |
Rudder | 2 spade rudders |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Guillaume Verdier Architecture Navale |
Website | http://www.guillaumeverdier.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Carbon fiber |
Number of spreaders | 2 |
Spreaders angle | Swept-back |
Upwind sail area | 115.01 sq.m |
Downwind sail area | 159.98 sq.m |
Spinnaker A | 1722.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 36 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.07 |
Upwind SA to Displacement | 42.92 |
Downwind SA to Displacement | 59.69 |
Hull Displacement Speed | 0.07 |
Capsize Screening Formula (CSF) | 2.63 |
