Boat Overview
- Type
- Maker
- Hull type
- Hull Material- Composite_Material
- Category
- Boat length (LOA)- 7.96 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Catalina Yachts |
| Maker website | https://www.catalinayachts.com |
| Model | Catalina 27 - Swing Keel |
| First built hull | 1971 |
| Version | Swing Keel |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Name | Value |
|---|---|
| Top speed | 10.06 kmh |
| Length overall | 7.96 m |
| Length at waterline | 6.43 m |
| Beam overall | 1.86 m |
| Draft maximum | 1.07 m |
| Displacement | 3,060.84 kg |
| Ballast weight | 1,179.79 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Frank Butler ; Robert Finch |
| Website | http://www.catalinayachts.com/ |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 31.68 sq.m |
| Mainsail A | 151.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Engine B |
Storage
| Name | Value |
|---|---|
| No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Upwind SA to Displacement | 15.28 |
| Displacement to Length (D/L) | 6.16 |
| Ballast to Displacement (B/D) | 0.39 |
| Capsize Screening Formula (CSF) | 1.29 |
