1996 Catalina Yachts Catalina 34 MkII - Wing Keel

No gallery images

1996 Catalina Yachts Catalina 34 MkII - Wing Keel

Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerCatalina Yachts
Maker websitehttps://www.catalinayachts.com
ModelCatalina 34 MkII - Wing Keel
First built hull1996
VersionWing Keel
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed11.78 kmh
Length overall10.91 m
Length at waterline8.87 m
Beam overall3.6 m
Draft maximum1.34 m
Displacement5,685 kg
Ballast weight2,537 kg
Ballast typeCast iron
Helm1 wheel
Rudder1 spade rudder
CockpitClosing aft cockpit with opening system
Designer
Naval architect
Name/StudioFrank Butler
Websitehttp://www.catalinayachts.com/
Rig & Sails
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders1
Spreaders angle0 °
Upwind sail area48.96 sq.m
Engine
Engine A
Power35 HP
TypeInboard
Storage

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 15.63
Upwind SA to Displacement15.63
Hull Displacement Speed 7.23
Displacement to Length (D/L) 227.05
Ballast to Displacement (B/D) 0.45
Capsize Screening Formula (CSF) 2.03
