Specs

Main
MakerCatalina Yachts
Maker websitehttps://www.catalinayachts.com
ModelCatalina 36 MkII - Tall Rig
First built hull1994
VersionTall Rig
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed11.86 kmh
Length overall11.09 m
Length at waterline9.2 m
Beam overall3.39 m
Draft maximum1.55 m
Displacement6,123 kg
Ballast weight2,722 kg
Ballast typeCast iron
Helm1 wheel
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioFrank Butler
Websitehttp://www.catalinayachts.com/
Rig & Sails
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders1
Spreaders angle0 °
Upwind sail area55.83 sq.m
Engine
Engine A
Power30 HP
TypeInboard
Storage
Fuel tank A124.92 liter
Water tank A180.19 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 16.96
Upwind SA to Displacement16.96
Hull Displacement Speed 7.36
Displacement to Length (D/L) 218.79
Ballast to Displacement (B/D) 0.44
Capsize Screening Formula (CSF) 1.87
