Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
4.63 m
Specs
Main
Name | Value |
---|---|
Maker | Catalina Yachts |
Maker website | https://www.catalinayachts.com |
Model | Catalina Expo 14.2 |
First built hull | 1997 |
Boat type | Sail |
Category | Dinghy Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 7.85 kmh |
Length overall | 4.63 m |
Length at waterline | 4.08 m |
Beam overall | 1.89 m |
Draft maximum | 1.1 m |
Displacement | 154.22 kg |
Helm | 1 tiller |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Frank Butler ; Garry Hoyt |
Website | http://www.garryhoyt.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast in Carbon fiber and boom in Aluminum |
Standing rigging | No standing rigging |
Upwind sail area | 9.66 sq.m |
Downwind sail area | 9.66 sq.m |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.04 |
Upwind SA to Displacement | 34.16 |
Downwind SA to Displacement | 34.16 |
Hull Displacement Speed | 0.04 |
Displacement to Length (D/L) | 4.91 |
Capsize Screening Formula (CSF) | 3.56 |
