Specs

Main
MakerCatalina Yachts
Maker websitehttps://www.catalinayachts.com
ModelCatalina 18 - Wing Keel
First built hull2000
VersionWing keel
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed8.72 kmh
Length overall6.22 m
Length at waterline5 m
Beam overall2.35 m
Draft maximum0.73 m
Displacement680 kg
Ballast weight193 kg
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Trailerable
Designer
Naval architect
Name/StudioGerry Douglas
Websitehttp://www.catalinayachts.com
Rig & Sails
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angleSwept-back
Upwind sail area16.07 sq.m
Engine
Engine A
TypeOutboard
Storage
Fuel tank A21.96 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 21.13
Upwind SA to Displacement21.13
Hull Displacement Speed 5.43
Displacement to Length (D/L) 151.71
Ballast to Displacement (B/D) 0.28
Capsize Screening Formula (CSF) 2.69
