1995 Catalina Yachts Catalina 22 MkII - Fin Keel

2475

Report error

1995 Catalina Yachts Catalina 22 MkII - Fin Keel

No galley images

1995 Catalina Yachts Catalina 22 MkII - Fin Keel
Preview

Boat Overview

  • Type
    Sail
  • Maker
    Catalina Yachts
  • Hull type
    Monohull
  • Hull Material
    Composite_material
  • Category
    Cruiser Boats
  • Boat length (LOA)
    7.04 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerCatalina Yachts
Maker websitehttps://www.catalinayachts.com/
ModelCatalina 22 MkII - Fin Keel
First built hull1995
VersionFin keel
Boat typeSail
Category Cruiser Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed9.48 kmh
Mast height8.87 m
Length overall7.04 m
Length at waterline5.91 m
Beam overall2.56 m
Headroom1.34 m
Draft maximum1.10 m
Displacement1181.15 kg
Ballast weight347.00 kg
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Trailerable
Designer
NameValue
Naval architect
Name/StudioFrank Butler
Websitehttp://www.catalinayachts.com/
Rig & Sails
NameValue
Mast29.1
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area19.14 sq.m
Mainsail A101.00
Engine
NameValue
Engine A
TypeOutboard engine ; Gas
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 8.54
Upwind SA to Displacement17.42
Hull Displacement Speed 5.9
Displacement to Length (D/L) 159.22
Ballast to Displacement (B/D) 29.38
Capsize Screening Formula (CSF) 2.44
