1995 Catalina Yachts Catalina 22 MkII - Wing keel

2002

Report error

1995 Catalina Yachts Catalina 22 MkII - Wing keel

No gallery images

1995 Catalina Yachts Catalina 22 MkII - Wing keel

Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerCatalina Yachts
Maker websitehttps://www.catalinayachts.com
ModelCatalina 22 MkII - Wing keel
First built hull1995
VersionWing keel
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed9.48 kmh
Mast height8.87 m
Length overall7.04 m
Length at waterline5.91 m
Beam overall2.56 m
Beam hull1.34 m
Draft maximum0.79 m
Displacement1,155 kg
Ballast weight321 kg
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Trailerable
Designer
Naval architect
Name/StudioFrank Butler
Websitehttp://www.catalinayachts.com/
Rig & Sails
Mast29.1
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area19.14 sq.m
Engine
Engine B
TypeOutboard
Storage
Fuel tank A23.09 liter
Water tank A17.03 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 17.68
Upwind SA to Displacement17.68
Hull Displacement Speed 5.9
Displacement to Length (D/L) 155.67
Ballast to Displacement (B/D) 0.28
Capsize Screening Formula (CSF) 2.46
