Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerCatalina Yachts
Maker websitehttps://www.catalinayachts.com
ModelCatalina 25 - Fin keel
First built hull1978
VersionFin keel
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed10.15 kmh
Length overall7.62 m
Length at waterline6.77 m
Beam overall2.44 m
Displacement2,064 kg
Ballast weight860 kg
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioFrank Butler
Websitehttp://www.catalinayachts.com/
Rig & Sails
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area25.08 sq.m
Engine
Storage

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 15.73
Upwind SA to Displacement15.73
Hull Displacement Speed 6.31
Displacement to Length (D/L) 185.65
Ballast to Displacement (B/D) 0.42
Capsize Screening Formula (CSF) 1.93
