Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
11.77 m
Specs
Main
Name | Value |
---|---|
Maker | Catalina Yachts |
Maker website | https://www.catalinayachts.com |
Model | Catalina 380 - Fin Keel |
First built hull | 1987 |
Version | Fin Keel |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 12.31 kmh |
Length overall | 11.77 m |
Length at waterline | 9.97 m |
Beam overall | 3.78 m |
Draft maximum | 2.13 m |
Displacement | 8,832.8 kg |
Ballast weight | 3,307.14 kg |
Ballast type | Lead |
Helm | 1 wheel |
Rudder | 1 spade rudder |
Cockpit | Closing aft cockpit with opening system |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Gerry Douglas |
Website | http://www.catalinayachts.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire |
Number of spreaders | 2 |
Spreaders angle | 0 ° |
Upwind sail area | 67.35 sq.m |
Engine
Name | Value |
---|---|
Engine A | |
Power | 42 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 16.03 |
Displacement to Length (D/L) | 7.66 |
Ballast to Displacement (B/D) | 0.37 |
Capsize Screening Formula (CSF) | 1.85 |
