Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
12.68 m
Specs
Main
| Maker | Catalina Yachts |
| Maker website | https://www.catalinayachts.com |
| Model | Catalina 400 MkII - Fin Keel |
| First built hull | 2000 |
| Version | Fin Keel |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 13.02 kmh |
| Mast height | 17.68 m |
| Length overall | 12.68 m |
| Length at waterline | 11.16 m |
| Beam overall | 4.15 m |
| Beam hull | 1.86 m |
| Draft maximum | 1.86 m |
| Displacement | 8,936.22 kg |
| Ballast weight | 3,265.86 kg |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Closing aft cockpit with opening system |
Designer
| Naval architect | |
| Name/Studio | Gerry Douglas |
| Website | http://www.catalinayachts.com |
Rig & Sails
| Mast | 58 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 75.07 sq.m |
Engine
| Engine A | |
| Power | 56 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Upwind SA to Displacement | 17.73 |
| Displacement to Length (D/L) | 8.11 |
| Ballast to Displacement (B/D) | 0.37 |
| Capsize Screening Formula (CSF) | 2.02 |
