Specs

Main
MakerCatalina Yachts
Maker websitehttps://www.catalinayachts.com
ModelCatalina 42 - Fin Keel
First built hull1989
VersionFin Keel
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed12.94 kmh
Mast height17.89 m
Length overall13.17 m
Length at waterline10.97 m
Beam overall3.99 m
Beam hull2.07 m
Draft maximum2.04 m
Displacement9,300 kg
Ballast weight3,765 kg
Helm1 wheel
Rudder1 spade rudder
CockpitClosing aft cockpit with opening system
Designer
Naval architect
Name/StudioNelson Marek
Websitehttp://www.catalinayachts.com/
Rig & Sails
Mast58.7
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area74.04 sq.m
Engine
Engine A
Power54 HP
TypeInboard
Storage
Fuel tank A174.13 liter
Water tank A420.18 liter
Water heater A42.02 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 17.02
Upwind SA to Displacement17.02
Hull Displacement Speed 8.04
Displacement to Length (D/L) 196.18
Ballast to Displacement (B/D) 0.4
Capsize Screening Formula (CSF) 1.92
