Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
17.13 m
Specs
Main
Name | Value |
---|---|
Maker | Catalina Yachts |
Maker website | https://www.catalinayachts.com |
Model | Catalina 545 |
First built hull | 2019 |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 15.32 kmh |
Mast height | 22.74 m |
Length overall | 17.13 m |
Length at waterline | 16.34 m |
Beam overall | 4.75 m |
Draft maximum | 1.95 m |
Displacement | 16,329.77 kg |
Ballast weight | 6,349.83 kg |
Helm | 2 wheels |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Gerry Douglas |
Website | http://www.catalinayachts.com/ |
Rig & Sails
Name | Value |
---|---|
Mast | 74.6 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire discontinuous |
Number of spreaders | 3 |
Spreaders angle | Swept-back |
Upwind sail area | 125.42 sq.m |
Engine
Name | Value |
---|---|
Engine A | |
Power | 110 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 19.82 |
Displacement to Length (D/L) | 9.81 |
Ballast to Displacement (B/D) | 0.39 |
Capsize Screening Formula (CSF) | 1.89 |
