Boat Overview

Boat Description

After several months of research and good advice from our most enthusiastic customers, the Catana shipyard, assisted by several architect firms is proud to present the brand new Catana 53.

The Catana Catamaran 53 is a boat that can take you to any destination you want. It's easy to use, and it has lots of space for your crew. This boat has been designed with all kinds of features that make it the perfect choice for any adventure.  It also has plenty of storage space so you can keep your belongings safe while traveling around on your travels!

The Catana 53 is a catamaran sailboat, designed for both sailing and cruising. Is a classic catamaran with a sleek, modern design. It's perfect for exploring the waters around you and making memories that will last a lifetime.



Specs

Main
NameValue
MakerCatana Catamarans
Maker websitehttps://www.catana.com
Model53
First built hull2017
Last built hull2019
Price1,300,000 €
Boat typeSail
CategoryCatamaran BoatsDaysailer Boats
Hull typeCatamaran Boats
Hull materialFiberglass
Cabins4
Births10
Heads5
General
NameValue
Length overall16.79 m
Beam overall8.69 m
Draft maximum2.77 m
Draft minimum0.79 m
Displacement14,499.98 kg
HelmTwin helm wheels
RudderTwin spade rudders
Designer
NameValue
Naval architect
Name/StudioCatana Design Office
Websitehttps://www.catanagroup.com/en/
Rig & Sails
NameValue
SparsAluminum spars
Standing rigging1x19 strand wire discontinuous
Number of spreaders1
Spreaders angleSwept-back
Upwind sail area180.05 sq.m
Downwind sail area273.04 sq.m
Mainsail A1184
Headsail A753
Spinnaker A1755
Engine
NameValue
Engine A
FuelDiesel
Power60 HP
TypeInboard
Engine B
FuelDiesel
Power60 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.06
Hull Displacement Speed 0.06
Capsize Screening Formula (CSF) 3.6
