Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
7.01 m
Specs
Main
| Maker | CNSO (Constructions Nautiques Du Sud-Ouest) |
| Model | Daïmio |
| First built hull | 1973 |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 9.37 kmh |
| Length overall | 7.01 m |
| Length at waterline | 5.52 m |
| Beam overall | 2.17 m |
| Beam hull | 1.65 m |
| Draft maximum | 1.13 m |
| Displacement | 1,399.78 kg |
| Ballast weight | 630.04 kg |
| Helm | 1 tiller |
| Rudder | 1 transom hung rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | François Sergent |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 31.12 sq.m |
| Downwind sail area | 56.49 sq.m |
Engine
| Engine A | |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 25.29 |
| Downwind SA to Displacement | 45.91 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 5.7 |
| Ballast to Displacement (B/D) | 0.45 |
| Capsize Screening Formula (CSF) | 1.96 |
