Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
8.44 m
Specs
Main
| Maker | CNSO (Constructions Nautiques Du Sud-Ouest) |
| Model | Super Daïmio Shoal draft |
| First built hull | 1975 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 10.33 kmh |
| Mast height | 11.43 m |
| Length overall | 8.44 m |
| Length at waterline | 7.01 m |
| Beam overall | 2.8 m |
| Beam hull | 1.56 m |
| Draft maximum | 1.43 m |
| Displacement | 3,000.06 kg |
| Ballast weight | 850.03 kg |
| Helm | 1 tiller |
| Rudder | 1 semi-spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | François Sergent |
Rig & Sails
| Mast | 37.5 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 42.64 sq.m |
| Downwind sail area | 74.97 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 16 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 20.85 |
| Downwind SA to Displacement | 36.66 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.43 |
| Ballast to Displacement (B/D) | 0.28 |
| Capsize Screening Formula (CSF) | 1.96 |
