Boat Overview

Boat Description

The Corsair 760 is incredibly easy to sail, even single-handed. Sometimes you choose to be sailing alone, and sometimes it just ends up that way with the crew asleep after a great summer’s day out on the water. All sail controls lead back to the cockpit. The Corsair 760 sails with almost zero heeling. It slips through the water with a minimum of fuss and gets you home quickly & safely.

The Corsair 760 offers sailors more comfort, performance and safety than our previous designs. This has been achieved by cleverly designing ultra modern high-volume, wave-piercing floats. This design offers additional buoyancy to significantly increasing the vessel's righting moments and safety margins.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerCorsair Marine
Maker websitehttps://www.corsairmarine.com
Model760
First built hull2016
VersionStandard
Price59,500 €
Boat typeSail
CategoryDaysailer BoatsHigh Performance BoatsTrimaran Boats
Hull typeTrimaran
Hull materialTrimaran
Births4
General
NameValue
Mast height10.52 m
Length overall7.38 m
Length at waterline7.22 m
Beam overall5.22 m
Headroom1.95 m
Draft maximum1.58 m
Displacement949.82 kg
HelmSingle helm tiller
RudderSingle transom hung rudder (main hull)
CockpitClosed aft cockpit
Trailerable
Designer
NameValue
Naval architect
Name/StudioDesign Team Corsair ; François Pérus
Websitehttp://www.perusyachtdesign.com/
Rig & Sails
NameValue
Rotating spars
Mast34.5
SparsAluminum Spars
Number of spreaders1
Spreaders angleSwept-back (diamond)
Upwind sail area38.18 sq.m
Downwind sail area82.5 sq.m
Mainsail A268
Headsail A143
Spinnaker A621
Spinnaker A262
Engine
NameValue
Engine A
FuelGas
Power8 HP
TypeOutboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.1
Upwind SA to Displacement40.19
Downwind SA to Displacement86.83
Hull Displacement Speed 0.1
Displacement to Length (D/L) 6.52
Capsize Screening Formula (CSF) 5.36
