Boat Overview

Boat Description

All Corsair trimarans are built to withstand the toughest conditions. But the Corsair 760 models including the Corsair 760 SPORT are finely tuned to turn numbers into results.

The Corsair 760 SPORT delivers supreme performance through the use of lightweight carbon technologies. However, she keeps the simple and effective sail plan, sail handling features, and folding mechanism that make the Corsair 760 so easy to manage. The carbon mast – standard on the Corsair 760 SPORT, reduces weight aloft and actually increasing her safety factor. So you can turn the speed dial to 10, but remain completely in control and comfortable in sailing such a performance machine. Superior safety is inherent in the design and construction of all Corsair boats.



Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerCorsair Marine
Maker websitehttps://www.corsairmarine.com
Model760 Sport
First built hull2016
VersionSport
Price59,500 €
Boat typeSail
CategoryDaysailer BoatsHigh Performance BoatsTrimaran Boats
Hull typeTrimaran
Hull materialTrimaran
Births4
General
NameValue
Mast height10.52 m
Length overall7.38 m
Length at waterline7.22 m
Beam overall5.22 m
Headroom1.95 m
Draft maximum1.58 m
Displacement874.98 kg
HelmSingle tiller
RudderSingle transom hung rudder (main hull)
CockpitClosed aft cockpit
Trailerable
Designer
NameValue
Naval architect
Name/StudioDesign Team Corsair ; François Pérus
Websitehttp://www.perusyachtdesign.com/
Rig & Sails
NameValue
Rotating spars
Mast34.5
SparsAluminum spars
Number of spreaders1
Spreaders angleSwept-back (diamond)
Upwind sail area38.18 sq.m
Downwind sail area82.5 sq.m
Mainsail A268
Headsail A143
Spinnaker A621
Spinnaker A262
Engine
NameValue
Engine A
FuelGas
Power8 HP
TypeOutboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.11
Upwind SA to Displacement42.45
Downwind SA to Displacement91.71
Hull Displacement Speed 0.11
Displacement to Length (D/L) 6.52
Capsize Screening Formula (CSF) 5.5
