Boat Overview

Boat Description

A combination of performance and comfort. The "970 Cruze" - this 32-footer combines the performance of the F-31 and comfort of the 37. While in Sport or Carbon guise this boat approaches the blistering speed of the Corsair 37.

For sailing performance, the high volume floats have been designed with additional buoyancy giving the Corsair 970 greater stability and comfort for her passengers. The saloon area is finished with a clean, white GRP liner. The galley is larger with additional drawers and ample storage. The forward and aft bunks are now longer and wider giving more generous accommodation area for crew. The Corsair 970 also caters for privacy with a fully enclosed head.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerCorsair Marine
Maker websitehttps://www.corsairmarine.com
Model970
First built hull2013
Price142,000 €
Boat typeSail
CategoryDaysailer BoatsHigh Performance BoatsTrimaran BoatsCenter Cockpit Boats
Hull typeTrimaran
Hull materialTrimaran
Cabins1
Births5
Heads1
General
NameValue
Mast height13.44 m
Length overall9.48 m
Length at waterline9.48 m
Beam overall6.92 m
Draft maximum1.86 m
Displacement1,813.91 kg
HelmSingle helm tiller
RudderSingle transom hung rudder (main hull)
CockpitCentral cockpit
Trailerable
Designer
NameValue
Naval architect
Name/StudioDesign Team Corsair
Websitehttp://www.corsairmarine.com/
Rig & Sails
NameValue
Rotating spars
Mast44.11
SparsAluminum spars
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angleSwept-back (diamond)
Upwind sail area58.99 sq.m
Downwind sail area130.99 sq.m
Mainsail A418
Headsail A217
Spinnaker A992
Spinnaker A448
Engine
NameValue
Engine A
FuelGas
Power20 HP
TypeOutboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.11
Upwind SA to Displacement40.34
Downwind SA to Displacement89.57
Hull Displacement Speed 0.11
Displacement to Length (D/L) 7.47
Capsize Screening Formula (CSF) 5.73
