Boat Overview

Boat Description

Dehler 45 sets entirely new standards in the class of the regatta cruisers: It convinces with exceptional sailing performance, best quality, made in Germany, highest safety level, abundance of space as well as multitude of technical innovations that bear typical Dehler handwriting. The Dehler 45 is both a high-performance regatta yacht with the highest speed potential and an elegant cruiser with first-class sail and typical home comfort.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerDehler
Maker websitehttps://www.hanseyachtsag.com/dehler
Model45
First built hull2011
VersionDeep/Shoal draft
Price229,000 €
Boat typeSail
CategoryDaysailer BoatsHigh Performance BoatsMotorsailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins3
Births8
Heads2
General
NameValue
Top speed13.52 kmh
Mast height20.88 m
Length overall13.44 m
Length at waterline12.01 m
Beam overall3.9 m
Headroom1.89 m
Draft maximum2.19 m
Displacement9,700.06 kg
Ballast weight3,529.85 kg
HelmTwin helm wheels
RudderSingle spade rudder
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioSimonis & Voogd Design
Websitehttp://www.simonis-voogd.com
Rig & Sails
NameValue
Mast68.5
SparsAluminum spars
Standing riggingDyform
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area121.98 sq.m
Downwind sail area222.97 sq.m
Mainsail A657
Headsail A657
Headsail B474
Spinnaker A1744
Spinnaker A1442
Engine
NameValue
Engine A
FuelDiesel
Power40 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.06
Upwind SA to Displacement27.28
Downwind SA to Displacement49.86
Hull Displacement Speed 0.06
Displacement to Length (D/L) 8.41
Ballast to Displacement (B/D) 0.36
Capsize Screening Formula (CSF) 1.85
